STS® Xpertjet 1682D DTF Printer

The STS XPJ 1682D 64” DTF Printer has a staggered dual-head design that provides ultra-fast print speeds. It produces smooth gradations while delivering high-quality printing even with reduced resolution. It has SAI’s Flexi DTF Pro Edition RIP Software, bundled with Flexi DTF Pro Editor. The XPJ-1682D also features automatic bi-directional alignments, a user-friendly touch panel, added LED lighting, and an upgraded media feed flange that allows operators to easily and quickly load media and exchange multiple rolls. These features are designed to increase user friendly operation and maintenance while continuing to offer high production, high-quality output. The XPJ-1682D is paired with STS’s DTF ink, which offers users excellent color gamut and outstanding durability.

Features:

• STS DTF Inks (CMYK Lm Lc White x8)
• Built-in color sensor for auto bi-directional.
• Improved feed mechanism corresponding to a wide range of media.
• Status Monitor (MSM) checks printer status in real time.
• Media flange allows for easy media loading.
• White ink circulation
• Nozzle area selection
• Drop Master 2 Technology

Specifications:

• Printing systems: Drop-on-demand Micro Piezo Inkjet Technology
• Print head height: Three level adjustment: Low 1.5mm, Mid. 2.5mm, High 4.0mm
• Print head: 2 (staggered set-up)
• Max print resolution: 1440x1440dpi
• Print modes: 1440/1080/720/360dpi
• Media width: 64”
• Media capacity: ø 5.9” dia / 2” & 3” cores /Roll media 66lbs or less
• Max media thickness: Low 0.3mm, Mid. 1.3mm, High 2.8mm
• Max printable width: 63.6 in
• Height adjustment: Automatic
• RIP software: Flexi21 DTF Pro Edition
• Ink Type: DTF Water Based
• Ink Set: CMYK Lm Lc White x8
• Ink Volume: 1000mL CMYK Lm Lc / 900mL White
• No. of slots: 8
• Interface: Gigabit-Ethernet (1000BASE-T )
• Power Requirements: AC 100-120V± 10%, 50/60Hz ± 1Hz
• Printable Environment: Temperature: 68-89.6°F | Humidity: 40-50% RH
  (non condensing) Rec. environment: Temperature: 71.6-86°F
• Power Consumption: Main: Operation status 77W or less | Standby: 52W or less
• Dimensions (WxDxH): Printer including stand: 108.26”x35.23”x56.22” cover closed
• Weight: Body: 321.87lb | Stand: 70.54lb
